| Model: | SK401 |
| Category： | Column Load Cells |
| Capacity: | 10,20,30,50N |
| Rated Output: | 2.0±10%mV/V |
| Material: | Stainless steel |
| Product Orgin: | China |
| The load cell can be customised for capacity, accuracy, dimension and other parameters. | |
SK401 Flange mounted Cylindrical force sensor s made of stainless steel and based on strain gauge technology with a trimmed 2.0mV/V output for tension and compression force measurements. The Column load cell offers four rated ranges of 0-10N / 0-20N / 0-30N / 0-20kg / 0-50N for force measurements and has a maximum non-linearity of 0.1% at full scale. You may find the column type force transducers suitable for in-line force monitoring, injection moulding machines, presses, material testing equipment and more.
| Specifications | Technique |
| Capacity | 10,20,30,50N |
| Rated output | 2.0±10%mV/V |
| Zero balance | ±2% F.S. |
| Non-linearity | 0.1%F.S. |
| Hysteresis | 0.1%F.S. |
| Repeatability | 0.1%F.S. |
| Temp.effect on output | 0.05%F.S./10℃ |
| Temp.effect on zero | 0.05%F.S./10℃ |
| Input impedance | 350±30Ω |
| Output impedance | 350±10Ω |
| Insulation | ≥5000MΩ/100VDC |
| Recommended excitation | 5~12V |
| Maximum excitation | 15V |
| Compensated temp range | -10~60℃ |
| Operation temp range | -20~80℃ |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Cable size | Φ2×3000mm |
